Features

5 Channel 2.4GHz Micro-Receiver
Extreme interference rejection
ultra-long range
Integral telemetry / servo bus (P²BUS)
High-performance real-time telemetry
Reception quality and airborne battery voltage available via telemetry as standard
Parameters for all functions can be set from the transmitter

Technical Data

Operating voltage	4.0V – 9.0V
Supported RC systems	CORE
Channels	26
Servo sockets	5
Servo signal resolution	4096 Steps
Supported telemetry systems	P²BUS
Dimensions	44 x 20 x 12 mm
Weight	7g

Temperature range

-30°C to +85°C

less

Product description

The receiver units

Five different receivers are available to match the CORE:

PBR-9D
This is a nine-channel receiver with two redundant receiver circuits. The unit features a P²BUS interface for servo and telemetry data, and an auxiliary output which can be configured either as SRXL bus or as channel 10.

PBR-7S
This is a seven-channel receiver with a single receiver circuit. The unit features a P²BUS interface for servo and telemetry data, and an auxiliary output which can be configured either as SRXL bus or as channel 8.

PBR-5S
This is a five-channel receiver with a single receiver circuit. The unit features a P²BUS interface for servo and telemetry data, while its minuscule size makes it the natural choice for small models.

PBR-26D
This is a satellite receiver featuring two redundant receiver circuits. The unit features a P²BUS interface for servo and telemetry data, and an auxiliary output which can be configured either as SRXL bus or S-BUS. This unit is designed to be connected to our PowerBox power supply systems or a flybarless system.

PBR-8E
This is a eight-channel receiver with two redundant receiver circuits. The unit features 8 PWM servo outputs and telemetry data for battery voltage and RF-data.

With the exception of the PBR-5S and the PBR-8E all receivers have a FastTrack interface with which the iGyro SAT can be easily connected!
